Magicycle Ocelot Step-Thru E-Bike

  • Sale
  • $1,799.00
  • Regular price $2,499.00
Shipping calculated at checkout.



Magicycle Ocelot Step-Thru Fat Tire E-Bike

PREMIUM STEP-THRU VERSATILE COMMUTING ELECTRIC BIKE

The Ocelot blends the convenience and versatility of a step-thru e-bike with the performance we’ve come to expect from Magicycle. It’s excellent for commuting and leisure rides, and super easy to get on and off thanks the lowest stand-over height among e-bike designs. You’ll be comfortable cruising over just about any terrain thanks to wide 4.0” fat tires that offer lots of grip and cushioning from the road’s imperfections. For added fun, pedal or throttle the powerful 500W or 750W motors to reach 40-45 km/h and ride up to 80 km on a single charge thanks to a large 52V 15Ah battery. Fun, zippy and convenient, the Magicycle Ocelot is your new favorite e-bike!

🇺🇸🍁  Free shipping in the US and Canada

😃  House of Bikes Exclusive: Free assembly and delivery!

🚚  Available in Ottawa, Montreal and Toronto areas

No License, No Insurance, No Registration Requirements


girl-with-white-magicycle-ocelot-electric-step-thru-fat-tire-e-bike

⚡ AT A GLANCE

  • 5-Level customizable pedal assistance + throttle
  • Step-thru, very low stand-over design
  • Two-year manufacturer's warranty

    🔋 Motor, Battery & Range

    • 500W motor (900W peak)
    • 750W motor (1,100W peak) [optional]
    • 52V / 15Ah lithium battery
    • Up to 80 km range

    🏁 Top Speed

    • Class 2: 32 km/h (20 mph)
    • Class 3 (500W): 40 km/h (25 mph)
    • Class 3 (750W): 45 km/h (28 mph)
    • Can be selected via display



    HIGHLIGHTS

    • Powerful brushless gear motor with 500W continuous, 900W peak power output
    • Optional 750W continuous, 1,100W peak output motor
    • High-capacity 52V / 15Ah lithium battery
    • Rated for a range of up to 80 kms (50 mi) on PAS level 1
    • 5-Level PAS (pedal assist system) with half-throttle and cadence sensor
    • 3 Amp smart, fast-charger capable of fully charging the battery in 3-5 hours
    • 4.0” wide fat tires for both on-road and off-road traction on sand, gravel, trails and snow
    • Tektro mechanical disc brakes
    • Full front suspension with 80mm front travel + lockout
    • LCD display with USB port for charging your smartphone and devices on the go
    • 350lbs total payload capacity
    • Shimano 7-speed drivetrain
    • Front & rear fenders to reduce splashing from water, mud and road grime
    • Front LED headlight and rear LED brake / taillight



      MODELS AND SPECS


      magicycle-ocelot-pro-electric-step-thru-fat-tire-e-bike-green-right-side

      Magicycle Ocelot Pro Step-Thru

      • 750W (1,100W peak) motor
      • 52V 20Ah longest-range battery
      • 45 km/h (28 mph) top speed
      • 130 km (80 mi) range
      • Hydraulic disc brakes
      • Full-color LCD display
      magicycle-ocelot-electric-step-thru-fat-tire-e-bike-gray-right-side

      Magicycle Ocelot Step-Thru (this one)

      • 500W (900W peak) motor
      • 750W (1,100W peak) optional
      • 52V 15Ah long-range battery
      • 40-45 km/h (25-28 mph) top speed
      • 80 km (50 mi) range
      • Mechanical disc brakes
      • Backlit display

      DO-ANYTHING VERSATILITY


      Commute to work, remain clean and comfortable, despite less flexibility from professional attire. Hop on and off the bike just as easily, whether you are tall, short, restricted in mobility or simply prefer the convenience of a step-thru bike.

      But the Magicycle Ocelot isn’t not all-work and no play! A high-performance motor, large battery capacity and 4” wide fat tires will have you enjoying its sporty nature. Capable of fast acceleration, long journeys and excellent braking, you’ll want to ride it just about anywhere and on any terrain thanks to wide 4” fat tires. Who says you can’t have it all?!




      FEATURES

      magicycle-deer-suv-ebike-full-suspension-electric-fat-bike-ebike-motor
      Powerful Motor - Equipped with a 500W motor peaking at 900W, it provides a great amount of torque. This allows for quick acceleration up to 40 km/h (25 mph). It also means you can easily climb a 20 degree slope. For even more power, the 750W motor (1,100W peak) is available, which can reach 45 km/h (28 mph) and climb 25 degree slopes.

      magicycle-deer-suv-ebike-full-suspension-electric-fat-bike-battery
      Long-Range 52V 15Ah Lithium Battery - High quality battery, specifically designed for long-lasting adventures with less battery loss. Enjoy commuting, scenic trips and trail rides with up to 80 km range.

      magicycle-ocelot-step-thru-e-bike-LCD-display
      Backlit Display - The backlit display shows important bike, battery and trip information, pedal assist level, speed and more. It also features a USB plug so you can keep your smartphone and devices charged on the go.

      magicycle-ocelot-step-thru-e-bike-mechanical-brakes
      Tektro Mechanical Disc Brakes - Efficient to slow you down quickly and confidently, even in inclement weather or down steep slopes.

      magicycle-ocelot-step-thru-e-bike-tires
      Kenda Anti-Puncture Tires - the premium tires from Kenda provide reflective sidewall stripes for enhanced visibility, and dual tread compound for longer tread life and secure grip even in wet or loose conditions. They feel at home on concrete as well as gravel paths and forest trails.

      magicycle-ocelot-step-thru-e-bike-suspension
      Zoom Hydraulic Front Fork – absorbs shocks and vibrations effectively while riding off-road. Featuring lockable and adjustable preload, the fork easily conquers any roads, reducing rider fatigue and makes for a smooth ride.

      magicycle-ocelot-step-thru-e-bike-taillight
      LED Taillight / Brake Light - stay safe and be seen, with an integrated taillight that lights up brighter upon even the slightest application of brakes.

      SPECIFICATIONS

      Battery 52V 15Ah lithium battery
      Range 30-55 miles
      Hub Motor 500W/900W brushless gear motor
      750W/1,100W brushless gear motor (optional)
      Display Backlight Display with USB Charging
      Total Payload
       Capacity
      350lbs
      Frame size 20"
      Charger Short-circuit proof 3.0A fast smart charger
      Controller 500W/900W or 750W/1,100W FOC smart controller,
      Current Range 7-22Ah (IPX8)
      Recommended
      Rider Heights
      4'10" - 6'2"
      Charging Time 3 - 5 Hours
      Weight 73lbs/33kg
      Pedal Assist Intelligent 5 levels pedal assist
      with 12 magnet cadence sensor

      COMPONENTS

      Tires Kenda 20"x4.0"
      Brake Lever Aluminum alloy comfort grip levers
      with motor cutoff switch
      Lights Integrated front light
      Crank 48T, 170mm forged alloy,
      dual-sided bashguard
      Brake Tektro Mechanical Disc Brakes
      Front Light 6V LED light
      Saddle Super Soft Cushion
      Seat Post Diameter 30.9mm length 300mm
      Kickstand Heavy Duty Aluminum
      Spokes 13 Gauge on the Front /
      12 Gauge on the Back
      Front Fork Alloy Mechanical lockout suspension fork
      Throttle Half twist throttle
      Freewheel Shimano-14-28T BROWN/BK
      Bike Frame 20" 6061 Aluminum Frame
      Package Dimension 153CM x 36CM x 88.5CM
      Chain KMC chain
      Stem MA-400 SSABK
      Pedal Wellgo alloy pedal with reflectors
      Gearing Shimano 7 Speed Gear Shift System

      GEOMETRY


      magicycle-ocelot-electric-step-thru-fat-tire-e-bike-geometry-1magicycle-ocelot-electric-step-thru-fat-tire-e-bike-geometry-2

      magicycle-electric-bike-rider-heights-for-ebikes

      magicycle-electric-bike-recommended-heights-ebike-chart

      ✶ Financing options available through PayPlan by RBC.
      ✶ Ships directly to you (90% assembled, easy-to-complete).
      ✶ Or you can pick it up assembled from House of Bikes in Ottawa - delivery available!
