Magicycle Deer SUV Full-Suspension Step-Over 26” Electric Fat Bike
POWERFUL HIGH-PERFORMANCE E-FAT BIKE
STEP-OVER DESIGN, REGULAR 18" FRAME SIZE
Meet the SUV of E-Bikes! The Magicycle Deer SUV is an ultra high-performance electric fat bike, with a very unique full-suspension set up. With superior shock absorption, you get unparalleled ride quality and comfort. It’s also one of the most powerful e-bikes available, thanks to an 1,100W peak motor with 96Nm of torque. Astonishingly, that means you can reach speeds up to 45km/h!
Cycle for longer distances with up to 130 kms range from the high-capacity 52V 20Ah battery from LG. Plus, this electric bike is available in 18” step-over and step-thru frames, and a smaller 16” frame with 20” wheels for shorter riders. The Magicycle Deer SUV E-Bike is truly suitable for cyclists of any height, weight and fitness level, wishing to adventure in Canada’s varied terrains and weather conditions.
🇺🇸🍁 Free shipping in the US and Canada
😃 House of Bikes Exclusive: Assembly and delivery!
🚚 Available in Ottawa, Montreal and Toronto areas
No License, No Insurance, No Registration Requirements
⚡ AT A GLANCE
- 7-Level customizable pedal assistance + throttle
- Full-suspension, step-over, mountain bike design
- Two-year manufacturer's warranty
✔️ AVAILABLE AS
- Step-Over, regular 18” frame with 26” tires (this one)
- Step-Thru, regular 18” frame with 26” tires
- Step-Thru, smaller 16” frame with 20” tires
🔋 Motor, Battery & Range
- 750W motor (1,100W peak) with 96 Nm torque
- LG 52V / 20Ah lithium battery
- Up to 130 km range
🏁 Top Speed
- Class 2: 32 km/h (20 mph)
- Class 3: 45 km/h (28 mph)
- Can be selected via display
Check it out
HIGHLIGHTS
- Full front & rear suspension with 80mm front travel + lockout and a rear coil with hydraulic damper.
- Very powerful brushless gear motor with 750W continuous and 1,100W peak power, able to easily climb a 25 degree incline.
- LG High-capacity 52V / 20Ah lithium battery, neatly integrated in the bike’s frame
- Rated for a range of up to 130 kms (80 mi) on PAS level 1.
- 7-Level PAS (pedal assist system) with half-throttle and cadence sensor.
- 3 Amp smart, fast-charger capable of fully charging the battery in 4-7 hours.
- 4.0” wide fat tires for both on-road and off-road traction on sand, gravel, trails and snow.
- Hydraulic disc brakes with large 180mm rotors.
- Full-Color LCD display with USB port for charging your smartphone and devices on the go.
- 400lbs total payload capacity.
- Cruise control.
- Shimano 7-speed drivetrain.
- Front & rear fenders to reduce splashing from water, mud and road grime.
- Heavy-duty rear rack with strap for storage and cargo use.
- Front LED headlight and rear LED brake / taillight.
- Regular (18”) frame size for step-over and step-thru 26” tire models.
- Smaller (16”) frame size for step-thru 20” tire model only.
MODELS AND SIZING
|
Deer SUV Model |
Frame Size |
Stand- Over |
Tire Size |
Height Range |
| Step-Over 26" | 18" | 33" | 26" x 4.0" | 5'5" - 6'8" |
| Step-Thru 26" | 18" | 27" | 26" x 4.0" | 5'5" - 6'8" |
| Step-Thru 20" | 16" | 24" | 20" x 4.0" | 4'10" - 6'2" |
 |
Deer SUV Step-Over Model (this one)
|
 |
|
 |
|
GO-ANYWHERE VERSATILITY
The Magicycle Deer SUV E-Bike is just as versatile as its performance. It’s the one bike you can take virtually anywhere. Want to go on an RV trip or bring it camping? Sure thing. What about getting around off-road on fishing or hunting trips? No problem.
Want to commute and ride it casually on streets and bike paths? It’s an excellent choice. And when you feel like taking a gravel road or ride light cross-country mountain bike trails, the full-suspension systems works wonders.
Of course, with 4.0” wide fat tires, you’ll just as easily cruise on a sandy beach or float over snow during winters. Just as an SUV is larger, more versatile and more comfortable than a car, so is the Deer compared to a conventional fat tire e-bike. So you really can do it all, with the Magicycle Deer SUV.
FEATURES
Super Powerful Motor - Equipped with a 750W peaking at 1,100W, the motor provides 96 Nm of torque. This allows for blistering acceleration up to 45 km/h (28 mph). It also means you can easily climb a 25 degree slope.
Long-Range LG 52V 20Ah Lithium Battery - High quality LG battery, specifically designed for long-lasting adventures with less battery loss. Enjoy commuting, scenic trips and trail rides with up to 130 km range.
Triangle Seatpost Structure - The stable design under the seat tube ensures stability of the seat post. Tha's how Magicycles makes Deer SUV the first step-thru full-suspension electric bike on the market.
Full-Suspension E-Bike System - In addition to the usual front suspension fork, the deer SUV has a coiled hydraulic rear shock. Stable, steady and capable of handling difficult technical trails, it creates a smoother ride with better traction and handling. It also reduces rider fatigue so you can enjoy longer bike rides.
Full-Color LCD Display - The color display on Deer provides a customizable user experience. You can program speed limits, power delivery of different levels of PAS, slow start, and more to meet your own needs and ride smarter.
180mm Hydraulic Disc Brakes - The brake efficiency is essential for a full-suspension E -bike. Magicycle Deer electric bicycles are equipped with Bengal hydraulic disc brakes, which provide superior brake efficiency in all conditions.
53 Tooth Large Front Chainring - No more ghost pedaling! The 7-speed gear set allows riders to reach a 3.8:1 gear ratio, which gets rid of ghost pedaling at higher speeds and leads to a better riding experience.
Soft Bike Seat - Magicycle bike seats are ergonomically designed to fit your body. They are shaped to match your riding position and will free you from strain and fatigue on longer rides.
SPECIFICATIONS
| Battery | 52V 20Ah LG lithium battery |
| Display | Color LCD Display with USB Charging |
| Charger | Short-circuit proof 3.0A fast smart charger |
| Charging Time | 4 - 7Hours |
| Range | 60-80 miles |
| Total Payload Capacity |
400lbs |
| Controller | 52V 750W FOC smart controller, Current Range 7-22Ah (IPX8) |
| Weight | 26" Deer: 92.3lbs/41.9kg ; 20" Deer: 83lbs/37.6kg |
| Hub Motor | 750W brushless gear motor(IP55) |
| Frame size | 26" Deer: 18" ; 20" Deer: 16" |
| Recommended Rider Heights |
26" Deer: 5'5" - 6'8" ; 20" Deer: 4'10" - 6'2" |
| Pedal Assist | 7-level Intelligent pedal assist with 12-magnet cadence sensor |
| Package Dimension | 20" Deer: 154CM x 32CM x 77.5CM; 26" Deer: 166CM x 33CM x 88.5CM |
COMPONENTS
| Tires | 26" Deer: Kenda 26"x4.0" Fat Tires ; 20" Deer: Kenda 20"x4.0" Fat Tires |
| Front Light | 6V LED light |
| Front Fork | Alloy Hydraulic lockout suspension fork |
| Chain | KMC chain |
| Brake Lever | Aluminum alloy comfort grip levers with motor cutoff switch |
| Saddle | Super Soft Cushion |
| Throttle | Half twist throttle |
| Stem | MA-400 SSABK |
| Lights | Integrated front and brake lights |
| Seat Post | Diameter 33.9mm length 250mm |
| Pedal | Wellgo alloy pedal with reflectors |
| Crank | 53T, 170mm forged alloy, dual-sided bashguard |
| Freewheel | Shimano-14-28T BROWN/BK |
| Kickstand | Heavy duty aluminum |
| Bike Frame | 26" Deer: 18" 6061 Aluminum Frame; 20" Deer: 16" 6061 Aluminum Frame |
| Bike Frame | 6061 Aluminum Frame |
| Gearing | Shimano 7 speed gear shift system |
| Brake | 180mm Hydraulic Disc Brakes |
| Spokes | 13 Gauge on the front / 12 Gauge on the back |
GEOMETRY
